Neo Series

rack-mount-model

Double Conversion On-Line UPS

  • True Sinewave Double Conversion On-line UPS
  • Multiple Microprocessor High Frequency design & DSP Technology
  • Near unity input power factor and wide input range
  • Extended backup time options available

Specifications

PHASE 1-Phase Input / 1-Phase Output
Model NEO- NEO- NEO- NEO- NEO- NEO- NEO-6000i NEO-10000i
1000i 1000iRM 2000i 2000iRM 3000i 3000iRM
KVA 1 kVA / 0.7 kW 2 kVA / 1.4 kW 3 kVA / 2.1 kW 6 kVA/4.2 kW  10 kVA/7 kW
Nominal Voltage  220/230/240VAC,  1p3w, resettable via LCD Front Panel 100/110/120VAC available for 1 – 3 kVA models* 220/230/240VAC,  1p3w,  resettable via LCD Front Panel
INPUT Input Range 160 – 300V [70% -100% Load], 140 – 300V [50% -70% Load], 176 – 276V
118 – 300VAC [0% – 50% load]
Input Frequency 50 / 60 Hz +/-4Hz
Power Factor ≥0.95 ≥0.97 ≥0.98
OUTPUT Output Voltage 200V* / 208V* / 220V / 230V / 240V   or   100V / 110V / 120V
Voltage Regulation + / – 2%
Wave Form Pure Sine Wave
Output Power Factor 0.7
Frequency Range Synchronized [Line Mode],  50 / 60 Hz + / – 0.05Hz [Battery Mode]
Current Crest Ratio 3:01
Overload Capacity 105%-125%:5mins,125%-150%:30secs,>150%:200ms <130%:10mins,>130%:1min
Voltage Tower ≤ 3 % @ linear load, ≤ 4 % @ linear load,
Distortion ≤6% @ non-linear ≤ 4% @ linear load, ≤7% @ non-linear load load ≤7% @ non-linear load
(THD) Rack ≤ 4 % @ linear load, ≤7% @ non-linear load NA
EFFICIENCY Inverter Mode
> 89%
>90% 90%
Battery Mode >83% >83% >83%
BATTERY Battery Type / Pcs Maintenance free lead-acid batteries
Rated Battery Voltage 36VDC 96VDC 240VDC
Backup Time (@ Full Load) >5 mins >9 mins >5 mins >8 mins >5 mins
Recharge Time / Charging current 5 hours to 90% 7 hours to 90% 8 hours to 90%
Maximum** 1A [8A option] 1A [8A option] 2A [4.2A] 2A [4.2A]
Battery Start  UPS can be started without AC source
TRANSFER TIME Battery Mode ↔ Inverter Mode 0ms
Inverter ↔ Bypass Mode 2.5ms 0ms
DISPLAY LCD UPS Status, I/P & O/P Voltage, Load %, Battery Capacity %, Temperature, ,Model Spec, Event log
LED Normal [Green], Bypass [Amber], Fault [Red]
AUDIBLE Battery Mode Beeping every 4 seconds [resettable]
ALARM Battery Low Beeping every second
Overload Beeping twice per second
Fault Beeping Continuously
OUTLETS Tower NEMA x 3 pcs or NEMA x 6 pcs or NEMA x 6 pcs or Terminal Blocks
[NEMA or IEC] IEC320 x 4 pcs IEC320 x 6 pcs IEC320 x 3 pcs + 1xTB Terminal Blocks
Rack NEMA x 4 pcs or NEMA x 2 pcs +1xTB  NEMA x 2 pcs + 1xTB   NA
[NEMA or IEC] IEC320 x 4 pcs or  IEC320 x 4 pcs IEC320 x 2 pcs+1xTB NA
DIMENSION Tower [whd] 160 x 220 x 400 mm 200 x 352 x 450 mm 260 x 717 x 570 mm
Rack [whd] 440 x 88 x 465 mm 440 x 88 x 465 mm x 2 modules NA
NETT WEIGHT Tower 15 kg 34 kg 35kg 90 kg 93 kg
Rack 15.5 kg
ENVIRONMENT Audible Noise < 45 dBA < 50 dBA < 55 dBA
Temperature 0 to 40°C  ( 32 to 104°F)
Humidity 0% – 90% (Non-Condensing)
Altitude <1000 M Above Sea Level
COMMUNICATION RS232 UPSilon Monitoring Software for Windows & Unix Systems
INTERFACE External slot Option for SNMP / AS400 Relay Card

*Models with 100/110/1120VAC end with suffix LV

** Extended Battery Backup Models are available with option for built-in 8A charger and 4A [2steps] charger for 6 kVA & 10 kVA

All specifications mentioned above are subject to change without prior notice
